SCANLAB Image Library

Here you'll find corporate and product images in print-quality resolution (300 dpi). You're free to use them for press purposes. When publishing an image, please include our copyright: © SCANLAB GmbH We always appreciate receiving specimen copies!

Corporate Pictures and People

30 Years of Scanlab Management

SCANLAB's management: Christian Huttenloher, COO (left) and Georg Hofner, CEO (right)

Georg Hofner SCANLAB CEO

Georg Hofner, CEO SCANLAB GmbH

Christian Huttenloher SCANLAB COO

Christian Huttenloher, COO SCANLAB GmbH

more

Product Pictures

varioSCAN II z-axis

varioSCAN II - the flexible z-axis generation

RTC6 EtherBox scanner control

RTC6 EtherBox: industrial-grade housing for advanced scan control

Laser Micro Drilling precSYS

Precision microdrilling of an injection nozzle (with femtosecond laser and 5-axis scan system) – Copyright stoba

more

Scan-Kopf SCANcube IV

SCANcube IV scan system

Scanlab Basic Cube

basiCube scan heads in preparation for shipment

RTC6 Ethernet control board

RTC6 Ethernet control board with counterfeit protection label

2D scan system, RTC6 control board

2D scan system, RTC6 control board and the 'Open Interface Extension' for fusion of laser process data

Simatic IPC427E Industrial PC with intelliSCAN scan head

Simatic IPC427E Industrial PC with intelliSCAN scan head and integrated RTC6 control board, and Simatic S7-1500 software controller, Simatic HMI

The fiberSYS scan head

The fiberSYS scan head is tailor-made for additive manufacturing applications

Limitless scanning of three-dimensional workpieces

Limitless scanning of three-dimensional workpieces with XL SCAN and integrated dynamic z-axis

The precSYS 515 micromachining system

The precSYS 515 micromachining system is optimized for 515-nm lasers

excelliSCAN 20 scan head

excelliSCAN 20 scan head ideally suited for micro machining and additive manufacturing

SCANLAB's basiCube 14 scan head

SCANLAB's basiCube 14 scan head: advanced laser marking performance at an entry-level price

Galvanometer scanner dynAXIS 421

Galvanometer scanner dynAXIS 421 for medical and scientific applications with diffrent servo-driver boards and mirror options

Scanning of virtually boundaryless image fields

Scanning of virtually boundaryless image fields with the XL SCAN: the combined solution for simultaneously controlling scan heads and XY stages

Processing results square bore holes

Processing results square bore holes - realized with precSYS integrated in a Posalux laser processing system

basiCube scan head with RTC5 control board

basiCube scan head with RTC5 control board

The excelliSCAN scan head

The excelliSCAN scan head is perfectly suited for laser micro-machining and additive manufacturing

Individualized customer service

Individualized customer service for the precSYS micromachining system

Software-based 3D Calibration Wizard

Screenshot of the software-based 3D Calibration Wizard

intelliSCANse 20 and 30

New digital-encoder -equipped 2D scan heads: intelliSCANse 20 and 30

powerSCAN II

powerSCAN II - 3D scan system for CO2 laser with variable image field

The syncAXIS control software

The syncAXIS control software enables simultaneous control of a 2D scan head and a 2D mechanical stage with two servo motors for simultaneous laser processing.

High-dynamics z-scanner excelliSHIFT

High-dynamics z-scanner excelliSHIFT for extending 2D scan systems

The CALsheet software - for better laser processing quality

Correction of system-specific errors with the CALsheet software - for better laser processing quality

welDYNA: scan system

welDYNA: scan system for oscillating-laser-beam cutting and welding

Collimation module for an easy coupling

Collimation module for an easy coupling of laser and scan system

The SCANcalc App

The SCANcalc App to simplify scan system selection

Laser engraving in glass

Laser engraving in glass, processed with a scan system like the basiCube 10 optimized for a 532 nm wavelength

Brand protection security label on SCANLAB's scan systems

SCANLAB's piracy protection

SCANLAB's piracy protection on galvanometer scanner

Blackbird Robotics's 2D scan system intelliSCAN FT

Blackbird Robotics's 2D scan system intelliSCAN FT for laser welding

Line Scan Engine (LSE) polygon scan system in production

Line Scan Engine (LSE) polygon scan system in production at Next Scan Technology

The laserDESK software version 1.2

A screenshot of the laserDESK software version 1.2

intelliWELD II FT

intelliWELD II FT with integrated zoom axis

200µm bore holes in steel drilled with precSYS

200µm bore holes in steel drilled with precSYS - compared to a human hair

High end scan system excelliSCAN

High end scan system excelliSCAN

RTC 4 Ethernet control board

RTC 4 Ethernet control board for cost-efficient industrial connectivity

intelliSCAN III 20

intelliSCAN III 20 – ideally suited for large-image field applications

SCANLAB galvo with digital se-encoder

SCANLAB galvo with digital se-encoder

digital encoder technology in a galvanometer scanner

Detail of SCANLAB's patented digital encoder technology in a galvanometer scanner
